Fluke 5560A, 5550A and 5540A Multi-Product Calibrators

Key features Intuitive calibration experience with 17.8 centimeter color touch screen Better match your existing digital multimeter workload with optimized ranging Easily calibrate meters that measure AC/DC voltage, resistance and capaci...

Genuine, authorised-distributor stock
Full manufacturer warranty & support
Calibration & traceability available

Overview

About the Fluke 5560A, 5550A

Product overview: Fluke 5560A, 5550A and 5540A Multi-Product Calibrators

A new patented ultra-linear analog-to-digital design enables the 5560A, 5550A and 5540A to achieve performance specifications that were not possible in the 5522A and 5502A, allowing you to calibrate a more accurate and demanding workload. Calibrate multimeters significantly faster with improved settling time in both the 5560A, 5550A and 5540A. You’ll have less wait time and more time actually performing the tests.

The 5560A, 5550A and 5540A multi-product calibrators work with MET/CAL, including hundreds of automated calibration procedures to consistently and dramatically improve throughput. MET/CAL v10.6 and later includes a Function Select Code (FSC) that enables you to add the 5560A, 5550A and 5540A seamlessly to your existing calibration operations.

5560A High-Performance Multi-Product Calibrator for comprehensive workload coverage

The 5560A calibrates the most popular benchtop 6.5-digit multimeters with better than 4:1 test uncertainty ratio (TUR), and clamp meters to 1500 A.

30 A continuous current output with no duty cycle and synthesized inductance functionality Calibrate modern and full-functional benchtop multimeters and clamp meters A new thermocouple connector enables easier connection and broadens the temperature workload coverage Use with a 52120A amplifier and appropriate coil to increase the current output to 6000 A 5550A Performance Multi-Product Calibrator for your multimeter workload

The 5550A enhances the 5522A Multi-Product Calibrator with new calibration ranges optimized to better match your existing digital multimeter workload in a modern, ruggedized instrument with an intuitive graphical interface.

30 A continuous current output Improved test uncertainty ratios (TURs) Use with a 52120A amplifier to increase the current output to 6000 A for calibrating high-current components such as Rogowski coils 5540A Multi-Product Calibrator for on-site and mobile calibration The 5540A extends the capabilities of the 5502A Multi-Product Calibrator with better performance suited for on-site or mobile calibration, covering many of the most demanding field instrumentation workloads. It calibrates the most popular handheld digital multimeters with increased test uncertainty ratios (TURs) and clamp meters to 1500 A with continuous current output.

30 A continuous current output Range redesign enables you to calibrate your existing handheld digital multimeters with greater confidence Use with a 52120A amplifier to increase the current output to 6000 A for calibrating high-current components such as Rogowski coils

FAQ

Fluke 5560A, 5550A and 5540A Multi-Product Calibrators: common questions

Is the Fluke 5560A, 5550A and 5540A Multi-Product Calibrators genuine and warranty-backed?

Yes. Measurands is an authorised distributor, so every Electrical Calibration instrument is genuine, carries the full manufacturer warranty and is supported with firmware and service — never a grey-market import.

Can you supply the Fluke 5560A, 5550A to Batam, Bintan or Singapore?

Yes — we supply Electrical Calibration instruments to customers across Singapore, Batam and Bintan. Request a quote with your application and we'll confirm availability, lead time and price.

Can it be supplied calibrated and traceable?

Yes. Through our sister calibration laboratory we can deliver the instrument calibrated with traceable documentation, so it is audit-ready on arrival.
